Product CatalogPart Number
JN5148/001,531
Manufacturer
NXP USA Inc.Description
IC RF TXRX+MCU 802.15.4 56VFQFN
Datasheet
DatasheetPackage
56-VFQFN
In Stock
39,986 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
JN5148/001,531
JN5148/001,531
lmages are for reference only.Payment Methods
Delivery Services
IC RF TxRx + MCU 802.15.4 Zigbee® 2.4GHz 56-VFQFN
Quick Inquiry
JN5148/001,531
Specifications
| Category | RF and Wireless - RF Transceiver ICs - |
| Manufacturer | NXP USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | TxRx + MCU |
| RF Family/Standard | 802.15.4 |
| Protocol | Zigbee® |
| Modulation | O-QPSK |
| Frequency | 2.4GHz |
| Data Rate (Max) | 667kbps |
| Power - Output | 2.75dBm |
| Sensitivity | -96.5dBm |
| Memory Size | 128kB ROM, 128kB RAM |
| Serial Interfaces | I2C, JTAG, SPI, UART |
| GPIO | 21 |
| Voltage - Supply | 2V ~ 3.6V |
| Current - Receiving | 17.5mA |
| Current - Transmitting | 15mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | - |
| Package / Case | 56-VFQFN |
| Supplier Device Package | - |
| Base Product Number | JN514 |
| Grade | - |
| Qualification | - |
