KAWD-2412EL
lmages are for reference only.KAWD-2412EL
DC DC CONVERTER +/-12V 30W
Datasheet8-DIP Module, 6 Leads
32,472 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module DC DC Converter 2 Output 12V -12V 1.25A, 1.25A 18V - 36V Input
KAWD-2412EL
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Diwell Electronics |
| Series | KAW-EL (30W) |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 18V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1.25A, 1.25A |
| Power (Watts) | 30 W |
| Applications | ITE (Commercial) |
| Features | Adjustable Output, Remote On/Off |
| Operating Temperature | -40°C ~ 71°C |
| Efficiency | 80% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP Module, 6 Leads |
| Size / Dimension | 2.00" L x 2.00" W x 0.43" H (50.8mm x 50.8mm x 11.0mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | - |
| Voltage - Isolation | 1.5 kV |
| Product Attribute | |
 |
 |
 |
| Part Number | KAWD-2412EL | KAWD-2415EL | KAWD-1205EL | KAWD-1212EL |
| Manufacturer | Diwell Electronics | Diwell Electronics | Diwell Electronics | Diwell Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER +/-12V 30W | DC DC CONVERTER +/-15V 30W | DC DC CONVERTER +/-5V 30W | DC DC CONVERTER +/-12V 30W |
| Series | Diwell Electronics | Diwell Electronics | Diwell Electronics | Diwell Electronics |
| Packaging | Tube | Tube | Tube | Tube |
