L6207D
lmages are for reference only.L6207D
IC HALF BRIDGE DRIVER 2.8A 24SO
Datasheet24-SOIC (0.295", 7.50mm Width)
69,258 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half Bridge (4) Driver DC Motors, Stepper Motors, Voltage Regulators DMOS 24-SO
L6207D
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge (4) |
| Applications | DC Motors, Stepper Motors, Voltage Regulators |
| Interface | Logic |
| Load Type | Inductive |
| Technology | DMOS |
| Rds On (Typ) | 300mOhm |
| Current - Output / Channel | 2.8A |
| Current - Peak Output | 5.6A |
| Voltage - Supply | 8V ~ 52V |
| Voltage - Load | 8V ~ 52V |
| Operating Temperature | -25°C ~ 125°C (TJ) |
| Features | Bootstrap Circuit |
| Fault Protection | Current Limiting, Over Temperature, UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 24-SO |
| Base Product Number | L6207 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | L6207D | L6207D013TR | L6207D013TR | L6207N |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC HALF BRIDGE DRIVER 2.8A 24SO | IC HALF BRIDGE DRIVER 2.8A 24SO | IC HALF BRIDGE DRIVER 2.8A 24SO | IC HALF BRIDG DRV 2.8A 24PWRDIP |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
