Amplifier IC 1-Channel (Mono) or 2-Channel (Stereo) Class AB 14-HSSOP
LA4814V-TLM-E
| Category | Integrated Circuits (ICs) - Linear - Amplifiers |
| Manufacturer | Sanyo |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Class AB |
| Output Type | 1-Channel (Mono) or 2-Channel (Stereo) |
| Max Output Power x Channels @ Load | 700mW x 1 @ 8Ohm |
| Voltage - Supply | 2.7V ~ 7V |
| Features | Depop, Standby |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Supplier Device Package | 14-HSSOP |
| Package / Case | 14-LSSOP (0.173", 4.40mm Width) + 2 Heat Tabs |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | LA4814V-TLM-E | LA4145-E | LA4192-E | LA42031-E |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | Not applicable | Not applicable | ||
| Description | IC AMP AB MON/STER 700MW 14HSSOP | AUDIO AMPLIFIER SE 1CH | AUDIO AMPLIFIER SE2CH/BTL | IC AMP CLASS AB MONO 5W 13SIPH |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Bulk | Bulk | Tube |
