LAY T67B-U1V1-1-1+U2V2-3-1-50-R18-Z
lmages are for reference only.LAY T67B-U1V1-1-1+U2V2-3-1-50-R18-Z
LED AMBER/YLW CLEAR 4PLCC SMD
Datasheet4-PLCC
74,811 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Amber, Yellow 617nm Amber, 585nm Yellow LED Indication - Discrete 2.1V Amber, 2.2V Yellow 4-PLCC
LAY T67B-U1V1-1-1+U2V2-3-1-50-R18-Z
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | ams-OSRAM USA INC. |
| Series | Hyper Multi TOPLED® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Color | Amber, Yellow |
| Configuration | Independent |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 675mcd Amber, 840mcd Yellow |
| Lens Style | Round with Flat Top |
| Lens Size | 2.40mm Dia |
| Voltage - Forward (Vf) (Typ) | 2.1V Amber, 2.2V Yellow |
| Current - Test | 50mA Amber, 50mA Yellow |
| Viewing Angle | 120° |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 617nm Amber, 585nm Yellow |
| Wavelength - Peak | 624nm Amber, 594nm Yellow |
| Features | - |
| Package / Case | 4-PLCC |
| Supplier Device Package | 4-PLCC |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Height (Max) | 2.10mm |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | LAY T67B-U1V1-1-1+U2V2-45-1-50-R18-Z-MM | LAY T67B-U1V1-1-1+U2V2-45-1-50-R18-Z-SV | LAY T67B-T1U2-1-1+V1V2-34-1-50-R18-Z | LAY T67B-T1V1-1-1+U2V2-45-1-50-R18-Z-HE |
| Manufacturer | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED AMBER/YLW CLEAR 4PLCC SMD | LED AMBER/YLW CLEAR 4PLCC SMD | LED AMBER/YLW CLEAR 4PLCC SMD | LED AMBER/YLW CLEAR 4PLCC SMD |
| Series | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
