LAYPH10040DL2R2NGA
Manufacturer
Taiyo YudenDescription
FIXED IND 2.2UH 3.1A 14 MOHM SMD
Datasheet
DatasheetPackage
Nonstandard
In Stock
31,975 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
LAYPH10040DL2R2NGA
LAYPH10040DL2R2NGA
lmages are for reference only.Payment Methods
Delivery Services
2.2 µH Shielded Wirewound Inductor 3.1 A 11mOhm Nonstandard
Quick Inquiry
LAYPH10040DL2R2NGA
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Taiyo Yuden |
| Series | LAYP |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 2.2 µH |
| Tolerance | ±30% |
| Current Rating (Amps) | 3.1 A |
| Current - Saturation (Isat) | 7.5A |
| Shielding | Shielded |
| DC Resistance (DCR) | 11mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 150°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.398" L x 0.394" W (10.10mm x 10.00mm) |
| Height - Seated (Max) | 0.169" (4.30mm) |
| Base Product Number | - |
