LC5768MV-5F256C
lmages are for reference only.LC5768MV-5F256C
IC CPLD 768MC 5NS 256FPBGA
Datasheet256-BGA
35,207 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LC5768MV-5F256C
| Category | Integrated Circuits (ICs) - Embedded - CPLDs Complex Programmable Logic Devices |
| Manufacturer | Lattice Semiconductor Corporation |
| Series | ispXPLD® 5000MV |
| Packaging | Tray |
| RoHS Status | RoHS non-compliant |
| Programmable Type | In System Programmable |
| Delay Time tpd(1) Max | 5 ns |
| Voltage Supply - Internal | 3V ~ 3.6V |
| Number of Logic Elements/Blocks | 24 |
| Number of Macrocells | 768 |
| Number of Gates | - |
| Number of I/O | 193 |
| Operating Temperature | 0°C ~ 90°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 256-BGA |
| Supplier Device Package | 256-FPBGA (17x17) |
| Base Product Number | LC5768 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LC5768MV-5F484C | LC5768MV-5FN256C | LC5768MV-5FN484C | LC5768MV-75F256C |
| Manufacturer | Lattice Semiconductor Corporation | Lattice Semiconductor Corporation | Lattice Semiconductor Corporation | Lattice Semiconductor Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ||
| Description | IC CPLD 768MC 5NS 484FPBGA | IC CPLD 768MC 5NS 256FPBGA | IC CPLD 768MC 5NS 484FPBGA | IC CPLD 768MC 7.5NS 256FPBGA |
| Series | ispXPLD® 5000MV | ispXPLD® 5000MV | ispXPLD® 5000MV | ispXPLD® 5000MV |
| Packaging | Tray | Tray | Tray | Tray |
