LD2-2R2-HV
Manufacturer
Eaton - Electronics DivisionDescription
IND DRUM CORE 2.2UH 5.0A
Datasheet
DatasheetPackage
Nonstandard
In Stock
20,934 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
LD2-2R2-HV
LD2-2R2-HV
lmages are for reference only.Payment Methods
Delivery Services
2.2 µH Unshielded Wirewound Inductor 20mOhm Max Nonstandard
Quick Inquiry
LD2-2R2-HV
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Eaton - Electronics Division |
| Series | LD2-HV |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 2.2 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | - |
| Current - Saturation (Isat) | 5A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 20mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -25°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.307" L x 0.276" W (7.80mm x 7.00mm) |
| Height - Seated (Max) | 0.209" (5.30mm) |
| Base Product Number | - |
