LD39030SJ25R
lmages are for reference only.LD39030SJ25R
IC REG LIN 2.5V 300MA 4FLIPCHIP
Datasheet4-UFBGA, FCBGA
26,137 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 300mA 4-Flipchip (0.79x0.79)
LD39030SJ25R
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 2.5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.3V @ 300mA |
| Current - Output | 300mA |
| Current - Quiescent (Iq) | 50 µA |
| PSRR | 62dB (1kHz ~ 10kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Soft Start |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-UFBGA, FCBGA |
| Supplier Device Package | 4-Flipchip (0.79x0.79) |
| Base Product Number | LD39030 |
| Current - Supply (Max) | 85 µA |
| Product Attribute |  |
 |
 |
 |
| Part Number | LD39030SJ10R | LD39030SJ12R | LD39030SJ15R | LD39030SJ18R |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 1V 300MA 4FLIPCHIP | IC REG LIN 1.2V 300MA 4FLIPCHIP | IC REG LIN 1.5V 300MA 4FLIPCHIP | IC REG LIN 1.8V 300MA 4FLIPCHIP |
| Series | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
