LFSPXO019242
lmages are for reference only.LFSPXO019242
XTAL OSC XO 3.6864MHZ HCMOS TTL
Datasheet4-SMD, No Lead
25,642 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
3.6864 MHz XO (Standard) HCMOS, TTL Oscillator 5V Standby (Power Down) 4-SMD, No Lead
LFSPXO019242
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | IQD Frequency Products |
| Series | CFPS-72 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | XO (Standard) |
| Frequency | 3.6864 MHz |
| Function | Standby (Power Down) |
| Output | HCMOS, TTL |
| Voltage - Supply | 5V |
| Frequency Stability | ±50ppm |
| Absolute Pull Range (APR) | - |
| Operating Temperature | 0°C ~ 70°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 20mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.283" L x 0.205" W (7.20mm x 5.20mm) |
| Height - Seated (Max) | 0.055" (1.40mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
 |
| Part Number | LFSPXO019079 | LFSPXO019079BULK | LFSPXO019080 | LFSPXO019080BULK |
| Manufacturer | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC XO 8.0000MHZ HCMOS TTL | XTAL OSC XO 8.0000MHZ HCMOS TTL | XTAL OSC XO 12.0000MHZ HCMOS TTL | XTAL OSC XO 12.0000MHZ HCMOS TTL |
| Series | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR) | Bulk |
