LFTVXO085764
lmages are for reference only.LFTVXO085764
XTAL OSC VCTCXO 20.0000MHZ HCMOS
Datasheet4-SMD, No Lead
31,222 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
20 MHz VCTCXO HCMOS Oscillator 3.3V Amplitude Control 4-SMD, No Lead
LFTVXO085764
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | IQD Frequency Products |
| Series | IQXT-200-47 |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | VCTCXO |
| Frequency | 20 MHz |
| Function | Amplitude Control |
| Output | HCMOS |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±100ppb |
| Absolute Pull Range (APR) | ±8ppm |
| Operating Temperature | -40°C ~ 105°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 10mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) |
| Height - Seated (Max) | 0.094" (2.40mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
 |
| Part Number | LFTVXO085760 | LFTVXO085761 | LFTVXO085762 | LFTVXO085763 |
| Manufacturer | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC VCTCXO 19.2000MHZ HCMOS | XTAL OSC VCTCXO 19.2000MHZ HCMOS | XTAL OSC VCTCXO 19.2000MHZ HCMOS | XTAL OSC VCTCXO 20.0000MHZ HCMOS |
| Series | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| Packaging | Strip | Strip | Strip | Strip |
