LM2724AMX
lmages are for reference only.LM2724AMX
IC DRIVER MOSFET DUAL SYNC 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
71,223 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
LM2724AMX
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 4.3V ~ 6.8V |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 3A, 3.2A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 28 V |
| Rise / Fall Time (Typ) | 17ns, 12ns |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | LM2724 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | LM2724AM/NOPB | LM2724AM/NOPB | LM2724AMX | LM2724AMX/NOPB |
| Manufacturer | Texas Instruments | National Semiconductor | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC GATE DRVR HALF-BRIDGE 8SOIC | HALF BRIDGE BASED MOSFET DRIVER | IC GATE DRVR HALF-BRIDGE 8SOIC | IC GATE DRVR HALF-BRIDGE 8SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tape & Reel (TR) |
