LM3100MH
lmages are for reference only.LM3100MH
IC REG BUCK ADJ 1.5A 20HTSSOP
Datasheet20-PowerTSSOP (0.173", 4.40mm Width)
14,991 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 1.5A 20-PowerTSSOP (0.173", 4.40mm Width)
LM3100MH
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Texas Instruments |
| Series | SIMPLE SWITCHER® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 36V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Voltage - Output (Max) | 7.2V |
| Current - Output | 1.5A |
| Frequency - Switching | Up to 1MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 20-PowerTSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 20-HTSSOP |
| Base Product Number | LM3100 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LM3100MH/NOPB | LM3100MHX | LM3100MHX/NOPB | LM3102MH/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG BUCK ADJ 1.5A 20HTSSOP | IC REG BUCK ADJ 1.5A 20HTSSOP | IC REG BUCK ADJ 1.5A 20HTSSOP | IC REG BUCK ADJ 2.5A 20HTSSOP |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
