LM338K STEEL/NOPB
lmages are for reference only.LM338K STEEL/NOPB
IC REG LINEAR POS ADJ 5A TO3-2
DatasheetTO-204AA, TO-3
58,310 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 5A TO-3-2
LM338K STEEL/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 40V |
| Voltage - Output (Min/Fixed) | 1.24V |
| Voltage - Output (Max) | 32V |
| Voltage Dropout (Max) | - |
| Current - Output | 5A |
| Current - Quiescent (Iq) | - |
| PSRR | 75dB ~ 60dB (120Hz) |
| Control Features | - |
| Protection Features | Over Temperature, Short Circuit |
| Operating Temperature | 0°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-204AA, TO-3 |
| Supplier Device Package | TO-3-2 |
| Base Product Number | LM338 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
|
 |
| Part Number | LM338K STEEL | LM104H/B | LM105H/B | LM1084IS-12/NOPB |
| Manufacturer | Texas Instruments | Rochester Electronics, LLC | Rochester Electronics, LLC | Texas Instruments |
| RoHS Status | ROHS3 Compliant | Not applicable | Not applicable | ROHS3 Compliant |
| Description | IC REG LINEAR POS ADJ 5A TO3-2 | IC REG LINEAR VOLTAGE NEG | LM105H/B | IC REG LIN 12V 5A DDPAK/TO263-3 |
| Series | Texas Instruments | Rochester Electronics, LLC | Rochester Electronics, LLC | Texas Instruments |
| Packaging | Tray | Bulk | Bulk | Tube |
