LM3543MX-H/NOPB
lmages are for reference only.LM3543MX-H/NOPB
IC PWR SWITCH N-CHAN 1:3 16SOIC
Datasheet16-SOIC (0.154", 3.90mm Width)
20,367 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Power Switch/Driver 1:3 N-Channel 500mA 16-SOIC
LM3543MX-H/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | USB Switch |
| Number of Outputs | 3 |
| Ratio - Input:Output | 1:3 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 500mA |
| Rds On (Typ) | 90mOhm |
| Input Type | Non-Inverting |
| Features | Status Flag |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 16-SOIC |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Base Product Number | LM3543 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LM3543MX-L | LM3543M-H/NOPB | LM3544M-H/NOPB | LM3544M-L |
| Manufacturer | National Semiconductor | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC SUPERVISOR PWR SUP SUPPORT | IC PWR SWITCH N-CHAN 1:3 16SOIC | IC PWR SWITCH N-CHAN 1:2 16SOIC | IC PWR SWITCH N-CHAN 1:2 16SOIC |
| Series | National Semiconductor | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Bulk | Tube | Tube | Tube |
