LNK6769K
lmages are for reference only.LNK6769K
IC OFFLINE SWITCH FLYBACK 12ESOP
Datasheet12-BESOP (0.350", 8.89mm Width), 11 Leads, Exposed Pad
39,470 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Flyback Topology 120kHz ~ 136kHz 12-ESOP
LNK6769K
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Power Integrations |
| Series | LinkSwitch™-HP |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Duty Cycle | 64% |
| Frequency - Switching | 120kHz ~ 136kHz |
| Power (Watts) | 77 W |
| Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit |
| Control Features | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | 12-BESOP (0.350", 8.89mm Width), 11 Leads, Exposed Pad |
| Supplier Device Package | 12-ESOP |
| Mounting Type | Surface Mount |
| Base Product Number | LNK6769 |
| Voltage - Start Up | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LNK6769E | LNK6769K-TL | LNK6769V | LNK6763E |
| Manufacturer | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | IC OFFLINE SWITCH FLYBACK 7ESIP | IC OFFLINE SWITCH FLYBACK 12ESOP | IC OFFLINE SWITCH FLYBACK 12EDIP | IC OFFLINE SWITCH FLYBACK 7ESIP |
| Series | LinkSwitch™-HP | LinkSwitch™-HP | LinkSwitch™-HP | LinkSwitch™-HP |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tube |
