LP3892ET-1.5/NOPB
lmages are for reference only.LP3892ET-1.5/NOPB
IC REG LINEAR 1.5V 1.5A TO220-5
DatasheetTO-220-5 Formed Leads
36,449 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 1.5A TO-220-5
LP3892ET-1.5/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1.5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.5V @ 1.5A |
| Current - Output | 1.5A |
| Current - Quiescent (Iq) | 30 µA |
| PSRR | 80dB ~ 65dB (120Hz ~ 1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-5 Formed Leads |
| Supplier Device Package | TO-220-5 |
| Base Product Number | LP3892 |
| Current - Supply (Max) | 8 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | LP3892ET-1.2/NOPB | LP3892ET-1.8/NOPB | LP3892EMR-1.2 | LP3892EMR-1.2/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 1.2V 1.5A TO220-5 | IC REG LINEAR 1.8V 1.5A TO220-5 | IC REG LIN 1.2V 1.5A 8SO PWRPAD | IC REG LIN 1.2V 1.5A 8SO PWRPAD |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tube | Tube | Tube | Tube |
