FIXED POSITIVE LDO REGULATOR
Datasheet10-WFDFN Exposed Pad
68,626 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 2 Output 150mA, 300mA 10-WSON (3x3)
LP5996SD-1018
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 2 |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 1V, 1.8V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.55V @ 300mA |
| Current - Output | 150mA, 300mA |
| Current - Quiescent (Iq) | 110 µA |
| PSRR | 70dB ~ 60dB (1kHz ~ 20kHz), 58dB ~ 45dB (1kHz ~ 20kHz) |
| Control Features | Enable |
| Protection Features | Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 10-WFDFN Exposed Pad |
| Supplier Device Package | 10-WSON (3x3) |
| Base Product Number | LP5996 |
| Current - Supply (Max) | 170 µA |
| Product Attribute |  |
 |
 |
|
| Part Number | LP5996SD-1018/NOPB | LP5996SD-1525/NOPB | LP5996SD-1833/NOPB | LP5996SD-1833/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | National Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC REG LINEAR 1V/1.8V 10SON | IC REG LINEAR 1.5V/2.5V 10SON | IC REG LINEAR 1.8V/3.3V 10SON | LP5996 DUAL LINEAR REGULATOR WIT |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | National Semiconductor |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
