LT3065EMSE-1.5#PBF
lmages are for reference only.LT3065EMSE-1.5#PBF
45V VIN, 500MILI AMP LOW NOISE,
Datasheet12-TSSOP (0.118", 3.00mm Width) Exposed Pad
21,610 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 500mA 12-MSOP-EP
LT3065EMSE-1.5#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 45V |
| Voltage - Output (Min/Fixed) | 1.5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.51V @ 500mA |
| Current - Output | 500mA |
| Current - Quiescent (Iq) | 110 µA |
| PSRR | 78dB (120Hz) |
| Control Features | Current Limit, Enable, Power Good, Soft Start |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 12-TSSOP (0.118", 3.00mm Width) Exposed Pad |
| Supplier Device Package | 12-MSOP-EP |
| Base Product Number | - |
| Current - Supply (Max) | 25 mA |
| Product Attribute | |
 |
 |
 |
| Part Number | LT3065EMSE-1.5#PBF | LT3065EMSE-1.5#TRPBF | LT3065EMSE-1.2#PBF | LT3065EMSE-1.2#TRPBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 1.5V 500MA 12MSOP | IC REG LINEAR 1.5V 500MA 12MSOP | IC REG LINEAR 1.2V 500MA 12MSOP | IC REG LINEAR 1.2V 500MA 12MSOP |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tape & Reel (TR) |
