LT3581HDE#PBF
lmages are for reference only.LT3581HDE#PBF
IC REG BST CHARGE PUMP ADJ 14DFN
Datasheet14-WFDFN Exposed Pad
17,341 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Boost, Charge Pump, Cuk, Flyback, SEPIC Switching Regulator IC Positive or Negative Adjustable 1.215V 1 Output 3.3A (Switch) 14-WFDFN Exposed Pad
LT3581HDE#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Function | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive or Negative |
| Topology | Boost, Charge Pump, Cuk, Flyback, SEPIC |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.5V |
| Voltage - Input (Max) | 22V |
| Voltage - Output (Min/Fixed) | 1.215V |
| Voltage - Output (Max) | 42V (Switch) |
| Current - Output | 3.3A (Switch) |
| Frequency - Switching | 200kHz ~ 2.5MHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 14-WFDFN Exposed Pad |
| Supplier Device Package | 14-DFN (4x3) |
| Base Product Number | LT3581 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | LT3581HDE#PBF | LT3581HDE#TRPBF | LT3001ES5#TRMPBF | LT3001ES5#TRPBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG BST CHARGE PUMP ADJ 14DFN | IC REG BST CHARGE PUMP ADJ 14DFN | IC REG FLYBACK 5V 1.2A TSOT23-5 | IC REG FLYBACK 5V 1.2A TSOT23-5 |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
