LTC3203EDD-1#PBF
lmages are for reference only.LTC3203EDD-1#PBF
IC REG CHARGE PUMP 4.5V/5V 10DFN
Datasheet10-WFDFN Exposed Pad
71,244 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Charge Pump Switching Regulator IC Positive Fixed 4.5V, 5V 1 Output 500mA 10-WFDFN Exposed Pad
LTC3203EDD-1#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Function | Step-Up |
| Output Configuration | Positive |
| Topology | Charge Pump |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.7V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 4.5V, 5V |
| Voltage - Output (Max) | 5V |
| Current - Output | 500mA |
| Frequency - Switching | 900kHz, 1MHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 10-WFDFN Exposed Pad |
| Supplier Device Package | 10-DFN (3x3) |
| Base Product Number | LTC3203 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | LTC3203EDD-1#PBF | LTC3203EDD-1#TRPBF | LTC3203EDD#PBF | LTC3203EDD#TRPBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG CHG PUMP PROG 500MA 10DFN | IC REG CHG PUMP PROG 500MA 10DFN | IC REG CHRG PUMP ADJ 500MA 10DFN | IC REG CHRG PUMP ADJ 500MA 10DFN |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR) |
