LTC5544IUF#TRPBF
lmages are for reference only.LTC5544IUF#TRPBF
LTC5544 - 4GHZ - 6GHZ HIGH DYNAM
Datasheet16-WQFN Exposed Pad
75,884 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Mixer IC Radar, WiMAX, WLAN Down Converter 4GHz ~ 6GHz 16-QFN (4x4)
LTC5544IUF#TRPBF
| Category | RF and Wireless - RF Mixers - |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| RF Type | Radar, WiMAX, WLAN |
| Frequency | 4GHz ~ 6GHz |
| Number of Mixers | 1 |
| Gain | 6.4dB |
| Noise Figure | 12.8dB |
| Secondary Attributes | Down Converter |
| Current - Supply | 194mA |
| Voltage - Supply | 3.1V ~ 3.5V |
| Mounting Type | Surface Mount |
| Package / Case | 16-WQFN Exposed Pad |
| Supplier Device Package | 16-QFN (4x4) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | LTC5544IUF#PBF | LTC5544IUF#TRPBF | LTC5540IUH#PBF | LTC5540IUH#TRPBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MIXER 4GHZ-6GHZ 16QFN | IC MIXER DOWN CONVERTER 16QFN | IC MIXER 600MHZ-1.3GHZ DWN 20QFN | IC MIXER 600MHZ-1.3GHZ DWN 20QFN |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tape & Reel (TR) |
