LTC7801HFE#TRPBF
lmages are for reference only.LTC7801HFE#TRPBF
IC REG CTRLR SYNC BUCK 24TSSOP
Datasheet24-TSSOP (0.173", 4.40mm Width) Exposed Pad
91,528 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Regulator Positive Output Step-Down DC-DC Controller IC 24-TSSOP
LTC7801HFE#TRPBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 4V ~ 140V |
| Frequency - Switching | 50kHz ~ 900kHz |
| Duty Cycle (Max) | 100% |
| Synchronous Rectifier | No |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Current Limit, Power Good, Soft Start, Tracking |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 24-TSSOP |
| Base Product Number | LTC7801 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LTC7801HFE#PBF | LTC7800EUDC#PBF | LTC7800EUDC#TRPBF | LTC7800HUDC#PBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG CTRLR SYNC BUCK 24TSSOP | IC REG CTRLR SYNC BUCK 60V 20QFN | IC REG CTRLR SYNC BUCK 60V 20QFN | IC REG CTRLR SYNC BUCK 60V 20QFN |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
