M0L1306QRHBRQ1
lmages are for reference only.M0L1306QRHBRQ1
AUTOMOTIVE 32-MHZ ARM CORTEX-M0+
Datasheet32-VFQFN Exposed Pad
39,066 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
ARM® Cortex®-M0+ - Microcontroller IC 32-Bit 32MHz 64KB (64K x 8) FLASH 32-VQFN (5x5)
M0L1306QRHBRQ1
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Core Processor | ARM® Cortex®-M0+ |
| Core Size | 32-Bit |
| Speed | 32MHz |
| Connectivity | DALI, I2C, IrDA, LINbus, SmartCard, SMBus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, TRNG, WDT |
| Number of I/O | 28 |
| Program Memory Size | 64KB (64K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 4K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.62V ~ 3.6V |
| Data Converters | A/D 10x12b SAR |
| Oscillator Type | External, Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount, Wettable Flank |
| Supplier Device Package | 32-VQFN (5x5) |
| Package / Case | 32-VFQFN Exposed Pad |
| Base Product Number | M0L1306 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | M0L1306QDGS20RQ1 | M0L1306QDGS28RQ1 | M0L1306QDGS32RQ1 | M0L1306QDYYRQ1 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | AUTOMOTIVE 32-MHZ ARM CORTEX-M0+ | AUTOMOTIVE 32-MHZ ARM CORTEX-M0+ | AUTOMOTIVE 32-MHZ ARM CORTEX-M0+ | AUTOMOTIVE 32-MHZ ARM CORTEX-M0+ |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
