MA4E2532M-1113
lmages are for reference only.MA4E2532M-1113
HMIC,SCH,SURMOUNT,MED BAR,RING Q
DatasheetDie
47,978 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Diode Schottky - 2 Pair Series 5V 20 mA 50 mW Die
MA4E2532M-1113
| Category | Discrete Semiconductor Products - Diodes - RF Diodes |
| Manufacturer | MACOM Technology Solutions |
| Series | MA4E2532 Surmount™ |
| Packaging | Tray |
| RoHS Status | |
| Base Product Number | MA4E2532 |
| Diode Type | Schottky - 2 Pair Series |
| Voltage - Peak Reverse (Max) | 5V |
| Current - Max | 20 mA |
| Capacitance @ Vr, F | 0.18pF @ 0V, 1MHz |
| Resistance @ If, F | 18Ohm @ 10.5mA, 1MHz |
| Power Dissipation (Max) | 50 mW |
| Operating Temperature | 175°C (TJ) |
| Package / Case | Die |
| Supplier Device Package | Die |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
 |
 |
| Part Number | MA4E2532L-1113 | MA4E1310 | MA4E1317 | MA4E1318 |
| Manufacturer | MACOM Technology Solutions | MACOM Technology Solutions | MACOM Technology Solutions | MACOM Technology Solutions |
| RoHS Status | Not applicable | ROHS3 Compliant | ROHS3 Compliant | |
| Description | HMIC SURMOUNT SCHOTTKY RING QUAD | GAAS_FLIP_CHIP | RF DIODE SCHOTTKY 7V | RF DIODE SCHOTTKY 7V |
| Series | MA4E2532 Surmount™ | - | - | - |
| Packaging | Tray | Bulk | Bulk | Bulk |
