MAAP-110150-TR0500
lmages are for reference only.MAAP-110150-TR0500
10-15GHZ, 2W, 5MM 24LQFN,T&R
Datasheet24-VQFN Exposed Pad
48,505 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Amplifier IC Cellular 10GHz ~ 15.35GHz 24-PQFN (5x5)
MAAP-110150-TR0500
| Category | RF and Wireless - RF Amplifiers - |
| Manufacturer | MACOM Technology Solutions |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Frequency | 10GHz ~ 15.35GHz |
| P1dB | 31.75dBm |
| Gain | 30dB |
| Noise Figure | - |
| RF Type | Cellular |
| Voltage - Supply | 5V |
| Current - Supply | 1.3A |
| Test Frequency | 13.25GHz |
| Mounting Type | Surface Mount |
| Package / Case | 24-VQFN Exposed Pad |
| Supplier Device Package | 24-PQFN (5x5) |
| Base Product Number | MAAP-110150 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MAAL-007304-TR3000 | MAAL-008624-TR3000 | MAAL-009053-TR3000 | MAAL-009120-TR3000 |
| Manufacturer | MACOM Technology Solutions | MACOM Technology Solutions | MACOM Technology Solutions | MACOM Technology Solutions |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC RF AMP GPS 500MHZ-3GHZ SOT26 | IC RF AMP CELL 400-500MHZ 8SOIC | IC RF AMP 800MHZ-3GHZ SC70-6 | IC RF AMP GPS 70MHZ-3GHZ SC70-6 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
