MAL250056152E3
lmages are for reference only.MAL250056152E3
CAP ALUM 1500UF 20% 400V SCREW
DatasheetRadial, Can - Screw Terminals
15,979 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1500 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 86mOhm @ 120Hz 3000 Hrs @ 85°C
MAL250056152E3
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components |
| Series | 500 PGP-ST |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 1500 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 86mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 14.1 A @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Lead Spacing | 0.874" (22.20mm) |
| Size / Dimension | 1.969" Dia (50.00mm) |
| Height - Seated (Max) | 4.362" (110.80mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Base Product Number | - |
| Impedance | 68 mOhms |
| Product Attribute | |
|
|
|
| Part Number | MAL250054102E3 | MAL250054103E3 | MAL250054122E3 | MAL250054152E3 |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP ALUM 1000UF 20% 420V SCREW | CAP ALUM 10000UF 20% 420V SCREW | CAP ALUM 1200UF 20% 420V SCREW | CAP ALUM 1500UF 20% 420V SCREW |
| Series | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| Packaging | Bulk | Bulk | Bulk | Bulk |
