MAN6750
lmages are for reference only.Payment Methods
Delivery Services
Display Modules - LED Character and Numeric Red 7-Segment 1.5 Character Common Cathode 2V (Max) 20mA 0.750" H x 0.985" W x 0.315" D (19.05mm x 25.02mm x 8.00mm) 18-DIP (0.600", 15.24mm), 15 Leads
MAN6750
| Category | Optoelectronics - LED Character and Numeric - |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Number of Characters | 1.5 |
| Size / Dimension | 0.750" H x 0.985" W x 0.315" D (19.05mm x 25.02mm x 8.00mm) |
| Digit/Alpha Size | 0.56" (14.22mm) |
| Display Type | 7-Segment |
| Common Pin | Common Cathode |
| Color | Red |
| Voltage - Forward (Vf) (Typ) | 2V (Max) |
| Current - Test | 20mA |
| Millicandela Rating | 0.42mcd |
| Wavelength - Peak | 650nm |
| Power Dissipation (Max) | 840mW |
| Package / Case | 18-DIP (0.600", 15.24mm), 15 Leads |
| Base Product Number | MAN67 |
| Display Format | - |
| Product Attribute | |
|
|
|
| Part Number | MAN6060 | MAN6080 | MAN6110E | MAN6111C |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ||||
| Description | DISPLAY 7SEG 0.56" SGL RED 10DIP | DISPLAY 7SEG 0.56" SGL RED 10DIP | DISPLAY 7SEG 0.56" DBL RED 18DIP | DISPLAY 7SEG 0.56" DBL RED 18DIP |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
