MAPLAD6.5KP85CAE3
lmages are for reference only.MAPLAD6.5KP85CAE3
TVS DIODE 85VWM 137VC MINI-PLAD
DatasheetNonstandard SMD
40,736 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
137V Clamp 47.5A Ipp Tvs Diode Surface Mount Mini-PLAD
MAPLAD6.5KP85CAE3
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 85V |
| Voltage - Breakdown (Min) | 94.4V |
| Voltage - Clamping (Max) @ Ipp | 137V |
| Current - Peak Pulse (10/1000µs) | 47.5A |
| Power - Peak Pulse | 6500W (6.5kW) |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard SMD |
| Supplier Device Package | Mini-PLAD |
| Base Product Number | - |
| Unidirectional Channels | - |
| Grade | Military |
| Qualification | MIL-PRF-19500 |
| Product Attribute | |
|
|
|
| Part Number | MAPLAD6.5KP85CA | MAPLAD6.5KP100A | MAPLAD6.5KP100AE3 | MAPLAD6.5KP100CA |
| Manufacturer | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | TVS DIODE 85VWM 137VC MINI-PLAD | TVS DIODE 100VWM 162VC MINI-PLAD | TVS DIODE 100VWM 162VC MINI-PLAD | TVS DIODE 100VWM 162VC MINI-PLAD |
| Series | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation |
| Packaging | Bulk | Bulk | Bulk | Bulk |
