MAX765CPA+
lmages are for reference only.MAX765CPA+
IC REG BUCK BOOST ADJ/-1V 8PDIP
Datasheet8-DIP (0.300", 7.62mm)
86,282 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck-Boost Switching Regulator IC Negative Adjustable (Fixed) -1V (-12V) 1 Output 120mA 8-DIP (0.300", 7.62mm)
MAX765CPA+
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Step-Up/Step-Down |
| Output Configuration | Negative |
| Topology | Buck-Boost |
| Output Type | Adjustable (Fixed) |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 3V |
| Voltage - Input (Max) | 16V |
| Voltage - Output (Min/Fixed) | -1V (-12V) |
| Voltage - Output (Max) | -16V |
| Current - Output | 120mA |
| Frequency - Switching | 300kHz |
| Synchronous Rectifier | No |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
| Base Product Number | MAX765 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MAX765CPA | MAX765CSA | MAX765CSA+ | MAX765CSA+T |
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG BUCK BOOST ADJ/-1V 8PDIP | IC REG BUCK BOOST ADJ/-1V 8SOIC | IC REG BUCK BOOST ADJ/-1V 8SOIC | IC REG BUCK BOOST ADJ/-1V 8SOIC |
| Series | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR) |
