MBRD20100CT-13
lmages are for reference only.MBRD20100CT-13
DIODE ARR SCHOT 100V 10A TO2523
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
69,823 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Diode Array 1 Pair Common Cathode 100 V 10A Surface Mount TO-252-3, DPAK (2 Leads + Tab), SC-63
MBRD20100CT-13
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Diode Configuration | 1 Pair Common Cathode |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Current - Average Rectified (Io) (per Diode) | 10A |
| Voltage - Forward (Vf) (Max) @ If | 840 mV @ 10 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 100 µA @ 100 V |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252-3 |
| Base Product Number | MBRD20100 |
| Reverse Recovery Time (trr) | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | MBRD20100CT | MBRD20100CTH-TP | MBRD10100CT | MBRD10100CT |
| Manufacturer | SMC Diode Solutions | Micro Commercial Co | Good-Ark Semiconductor | Littelfuse Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | DIODE ARRAY SCHOTTKY 100V DPAK | DIODE ARRAY SCHOTT 100V 20A DPAK | DIODE ARRAY SCHOT 100V 10A TO252 | DIODE ARRAY SCHOTT 100V 5A TO252 |
| Series | - | - | - | MBR |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
