NAND Gate IC 4 Channel Schmitt Trigger 14-SOIC
MC74HC132AFR1
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Motorola |
| Series | 74HC |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | 74HC132 |
| Logic Type | NAND Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | Schmitt Trigger |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Max) | 1 µA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Input Logic Level - Low | 0.3V ~ 1.2V |
| Input Logic Level - High | 1.5V ~ 4.2V |
| Max Propagation Delay @ V, Max CL | 21ns @ 6V, 50pF |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Package / Case | 14-SOIC (0.209", 5.30mm Width) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | MC74HC132AFR2 | MC74HC132ADG | MC74HC132ADG | MC74HC132ADR2G |
| Manufacturer | onsemi | onsemi | Motorola | onsemi |
| RoHS Status | Not applicable | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC GATE NAND 4CH 2-INP 14SOIC | IC GATE NAND 4CH 2-INP 14SOIC | IC GATE NAND 4CH 2-INP 14SOIC | IC GATE NAND 4CH 2-INP 14SOIC |
| Series | 74HC | 74HC | 74HC | 74HC |
| Packaging | Bulk | Tube | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
