MC9S08JS8LCFK
lmages are for reference only.MC9S08JS8LCFK
IC MCU 8BIT 8KB FLASH 24QFN
Datasheet24-VQFN Exposed Pad
79,732 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
S08 S08 Microcontroller IC 8-Bit 48MHz 8KB (8K x 8) FLASH 24-HVQFN (5x5)
MC9S08JS8LCFK
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Freescale Semiconductor |
| Series | S08 |
| Packaging | Bulk |
| RoHS Status | |
| Core Processor | S08 |
| Core Size | 8-Bit |
| Speed | 48MHz |
| Connectivity | LINbus, SCI, SPI, USB |
| Peripherals | LVD, POR, PWM |
| Number of I/O | 14 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 512 x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Data Converters | - |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 24-HVQFN (5x5) |
| Package / Case | 24-VQFN Exposed Pad |
| Base Product Number | MC9S08 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | MC9S08JS8LCFK | MC9S08JS8LCWJ | MC9S08JS8LCWJ | MC9S08JE128CLH |
| Manufacturer | NXP USA Inc. | Freescale Semiconductor | NXP USA Inc. | Freescale Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC MCU 8BIT 8KB FLASH 24QFN | IC MCU 8BIT 8KB FLASH 20SOIC | IC MCU 8BIT 8KB FLASH 20SOIC | IC MCU 8BIT 128KB FLASH 64LQFP |
| Series | NXP USA Inc. | Freescale Semiconductor | NXP USA Inc. | Freescale Semiconductor |
| Packaging | Tray | Bulk | Tube | Bulk |
