MC9S08QG8MDNE
lmages are for reference only.MC9S08QG8MDNE
IC MCU 8BIT 8KB FLASH 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
78,293 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
S08 S08 Microcontroller IC 8-Bit 20MHz 8KB (8K x 8) FLASH 8-SOIC
MC9S08QG8MDNE
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Freescale Semiconductor |
| Series | S08 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Core Processor | S08 |
| Core Size | 8-Bit |
| Speed | 20MHz |
| Connectivity | I2C, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Number of I/O | 4 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 512 x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Data Converters | A/D 4x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SOIC |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Base Product Number | MC9S08 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
|
| Part Number | MC9S08QG8MDNE | MC9S08QG8MFFE | MC9S08QG8MFQE | MC9S08QG8MFQE |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | Freescale Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC MCU 8BIT 8KB FLASH 8SOIC | IC MCU 8BIT 8KB FLASH 16QFN | IC MCU 8BIT 8KB FLASH 8DFN | IC MCU 8BIT 8KB FLASH 8DFN |
| Series | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | Freescale Semiconductor |
| Packaging | Tube | Tray | Tray | Bulk |
