MCA2255SMT&R
lmages are for reference only.MCA2255SMT&R
6PIN NON-BASE LEAD DARLINGTON OU
Datasheet6-SMD, Gull Wing
89,609 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Darlington with Base Output 5300Vrms 1 Channel 6-SMD
MCA2255SMT&R
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | Isocom Components 2004 LTD |
| Series | MCA2255 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 5300Vrms |
| Current Transfer Ratio (Min) | 500% @ 10mA |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | 10µs, 100µs |
| Rise / Fall Time (Typ) | - |
| Input Type | DC |
| Output Type | Darlington with Base |
| Voltage - Output (Max) | 55V |
| Current - Output / Channel | - |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 80 mA |
| Vce Saturation (Max) | 1V |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, Gull Wing |
| Supplier Device Package | 6-SMD |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MCA2255 | MCA2255G | MCA2255SM | MCT66XG |
| Manufacturer | Isocom Components 2004 LTD | Isocom Components 2004 LTD | Isocom Components 2004 LTD | Isocom Components 2004 LTD |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 6PIN NON-BASE LEAD DARLINGTON OU | 6PIN NON-BASE LEAD DARLINGTON OU | 6PIN NON-BASE LEAD DARLINGTON OU | 8PIN TRANSISTOR OUTPUT, DUAL CHA |
| Series | MCA2255 | MCA2255 | MCA2255 | MCT66 |
| Packaging | Tube | Tube | Tube | Tube |
