MCM01-001D220J-F
lmages are for reference only.MCM01-001D220J-F
CAP PTFE 22PF 5% 500V SMD
DatasheetNonstandard SMD
77,623 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
22 pF Polytetrafluoroethylene (PTFE) Capacitor 500 V Nonstandard SMD
MCM01-001D220J-F
| Category | Capacitors - Mica and PTFE Capacitors - |
| Manufacturer | Cornell Dubilier Knowles |
| Series | MCM01 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 22 pF |
| Tolerance | ±5% |
| Voltage - Rated | 500 V |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -55°C ~ 200°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard SMD |
| Lead Spacing | - |
| Features | RF, High Frequency |
| Size / Dimension | 0.460" L x 0.400" W (11.68mm x 10.16mm) |
| Height - Seated (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MCM01-001D220G-F | MCM01-001D220K-F | MCM01-001D030D-F | MCM01-001D060D-F |
| Manufacturer | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP PTFE 22PF 2% 500V SMD | CAP PTFE 22PF 10% 500V SMD | CAP PTFE 3PF 0.5PF 500V SMD | CAP PTFE 6PF 0.5PF 500V SMD |
| Series | MCM01 | MCM01 | MCM01 | MCM01 |
| Packaging | Bulk | Bulk | Bulk | Tape & Reel (TR) |
