Product CatalogPart Number
MIXA81H1200EH
Manufacturer
IXYSDescription
IGBT MODULE 1200V 120A 390W E3
Datasheet
DatasheetPackage
E3
In Stock
13,879 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MIXA81H1200EH
MIXA81H1200EH
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module PT Full Bridge Inverter 1200 V 120 A 390 W Chassis Mount E3
Quick Inquiry
MIXA81H1200EH
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | IXYS |
| Series | - |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | PT |
| Configuration | Full Bridge Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 120 A |
| Power - Max | 390 W |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 77A |
| Current - Collector Cutoff (Max) | 200 µA |
| Input Capacitance (Cies) @ Vce | - |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | E3 |
| Supplier Device Package | E3 |
| Base Product Number | MIXA81 |
