MM70-314B2-1-R500
Manufacturer
JAE ElectronicsDescription
CONN MXM 3.0 FMALE 314POS 0.020
Datasheet
DatasheetPackage
-
In Stock
36,763 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MM70-314B2-1-R500
MM70-314B2-1-R500
lmages are for reference only.Payment Methods
Delivery Services
314 Position Female Connector MXM 3.0 Gold 0.020" (0.50mm) Black
Quick Inquiry
MM70-314B2-1-R500
Specifications
| Category | Connectors, Interconnects - Card Edge Connectors - Edgeboard Connectors |
| Manufacturer | JAE Electronics |
| Series | MM70 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Card Type | MXM 3.0 |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 314 |
| Card Thickness | 0.047" (1.20mm) |
| Number of Rows | 2 |
| Pitch | 0.020" (0.50mm) |
| Read Out | Dual |
| Features | - |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | 11.8µin (0.30µm) |
| Contact Type | - |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -40°C ~ 85°C |
| Material - Insulation | Liquid Crystal Polymer (LCP), Glass Filled |
| Termination Rows | - |
| Base Product Number | - |
