MMD-10DZ-R45M-X1
lmages are for reference only.MMD-10DZ-R45M-X1
FIXED IND 450NH 25A 1.3 MOHM SMD
DatasheetNonstandard
67,529 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
450 nH Shielded Molded Inductor 25 A 1.3mOhm Max Nonstandard
MMD-10DZ-R45M-X1
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Pulse Electronics |
| Series | MMD-10DZ-X1 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Molded |
| Material - Core | Metal |
| Inductance | 450 nH |
| Tolerance | ±20% |
| Current Rating (Amps) | 25 A |
| Current - Saturation (Isat) | 27A |
| Shielding | Shielded |
| DC Resistance (DCR) | 1.3mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.453" L x 0.394" W (11.50mm x 10.00mm) |
| Height - Seated (Max) | 0.157" (4.00mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | MMD-10DZ-R19M-V1 | MMD-10DZ-R19M-V1 | MMD-10DZ-R45M-X1 | MMD-10DZ-1R0M-V1 |
| Manufacturer | Pulse Electronics | Pulse Electronics | Pulse Electronics | Pulse Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 190NH 40A 0.95MOHM SMD | FIXED IND 190NH 40A 0.95MOHM SMD | FIXED IND 450NH 25A 1.3 MOHM SMD | FIXED IND 1UH 17.5A 4.1 MOHM SMD |
| Series | Pulse Electronics | Pulse Electronics | Pulse Electronics | Pulse Electronics |
| Packaging | Tape & Box (TB) | Tape & Box (TB) | Tape & Reel (TR) | Tape & Reel (TR) |
