MMZ1608D121BTD25
lmages are for reference only.MMZ1608D121BTD25
FERRITE BEAD 120 OHM 0603 1LN
Datasheet0603 (1608 Metric)
51,631 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
120 Ohms @ 100 MHz 1 Signal Line Ferrite Bead 0603 (1608 Metric) 400mA 300mOhm
MMZ1608D121BTD25
| Category | Filters - Ferrite Beads and Chips - |
| Manufacturer | TDK Corporation |
| Series | MMZ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Signal Line |
| Number of Lines | 1 |
| Impedance @ Frequency | 120 Ohms @ 100 MHz |
| Current Rating (Max) | 400mA |
| DC Resistance (DCR) (Max) | 300mOhm |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 125°C |
| Package / Case | 0603 (1608 Metric) |
| Mounting Type | Surface Mount |
| Height (Max) | 0.037" (0.95mm) |
| Size / Dimension | 0.063" L x 0.032" W (1.60mm x 0.80mm) |
| Features | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MMZ1608D121BTA00 | MMZ1608D121CTAH0 | MMZ1608D121CTDH5 | MMZ1608A152ETA00 |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FERRITE BEAD 120 OHM 0603 1LN | FERRITE BEAD 120 OHM 0603 1LN | FERRITE BEAD 120 OHM 0603 1LN | FERRITE BEAD 1.5K OHM 0603 1LN |
| Series | MMZ | MMZ | MMZ | MMZ-E |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
