MOC5009SM
lmages are for reference only.MOC5009SM
6PIN SCHMITT TRIGGER, SINGLE OPT
Datasheet6-SMD (0.300", 7.62mm)
59,039 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Logic Output Optoisolator 1MHz Tri-State 5300Vrms 1 Channel CMTI 6-SMD
MOC5009SM
| Category | Isolators - Optoisolators - Logic Output Optoisolators |
| Manufacturer | Isocom Components 2004 LTD |
| Series | MOC500 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Inputs - Side 1/Side 2 | 1/0 |
| Voltage - Isolation | 5300Vrms |
| Common Mode Transient Immunity (Min) | - |
| Input Type | DC |
| Output Type | Tri-State |
| Current - Output / Channel | 50 mA |
| Data Rate | 1MHz |
| Propagation Delay tpLH / tpHL (Max) | - |
| Rise / Fall Time (Typ) | 100ns, 100ns |
| Voltage - Forward (Vf) (Typ) | 1.5V (Max) |
| Current - DC Forward (If) (Max) | 50mA |
| Voltage - Supply | 16V |
| Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD (0.300", 7.62mm) |
| Supplier Device Package | 6-SMD |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
 |
| Part Number | MOC5009SM | MOC5009SM | MOC5009SM | MOC5009SMT&R |
| Manufacturer | Isocom Components 2004 LTD | onsemi | onsemi | Isocom Components 2004 LTD |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | 6PIN SCHMITT TRIGGER, SINGLE OPT | OPTOCOUPLER SCHMIT TRIG LP SMD | OPTOCOUPLER SCHMIT TRIG LP SMD | 6PIN SCHMITT TRIGGER, SINGLE OPT |
| Series | MOC500 | GlobalOptoisolator™ | GlobalOptoisolator™ | MOC500 |
| Packaging | Tube | Bag | Bag | Tape & Reel (TR) |
