MPDKN118S
lmages are for reference only.MPDKN118S
DC DC CONVERTER 5V 65W
Datasheet8-DIP Module, 1/8 Brick
43,785 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 5V 13A 36V - 75V Input
MPDKN118S
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Murata Power Solutions Inc. |
| Series | MPD |
| Packaging | Tray |
| RoHS Status | |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 36V |
| Voltage - Input (Max) | 75V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 13A |
| Power (Watts) | 65 W |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 90% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP Module, 1/8 Brick |
| Size / Dimension | 2.24" L x 0.86" W x 0.35" H (56.9mm x 21.9mm x 9.0mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | MPDKN |
| Voltage - Isolation | 1.5 kV |
| Product Attribute |  |
|
 |
|
| Part Number | MPDKN117S | MPDKN117S | MPD30-12S12 | MPD30-12S12 |
| Manufacturer | Murata Power Solutions Inc. | Murata Power Solutions Inc. | P-DUKE Technology | P-DUKE Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | DC DC CONVERTER 3.3V 66W | DC DC CONVERTER 3.3V 66W | DC DC CONVERTER 12V 30W | DC DC CONVERTER 12V 30W |
| Series | Murata Power Solutions Inc. | Murata Power Solutions Inc. | P-DUKE Technology | P-DUKE Technology |
| Packaging | Tray | Tray | Tube | Tube |
