MPXA4100AC6U
lmages are for reference only.MPXA4100AC6U
SENSOR 15.23PSIA 0.13" 49V
Datasheet8-SMD, Gull Wing, Top Port
54,689 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor 2.9PSI ~ 15.23PSI (20kPa ~ 105kPa) Absolute Male - 0.13" (3.17mm) Tube 0.3 V ~ 49 V 8-SMD, Gull Wing, Top Port
MPXA4100AC6U
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | NXP USA Inc. |
| Series | MPXA4100A |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | MPXA41 |
| Applications | Board Mount |
| Pressure Type | Absolute |
| Operating Pressure | 2.9PSI ~ 15.23PSI (20kPa ~ 105kPa) |
| Output Type | Analog Voltage |
| Output | 0.3 V ~ 49 V |
| Accuracy | ±1.8% |
| Voltage - Supply | 4.85V ~ 5.35V |
| Port Size | Male - 0.13" (3.17mm) Tube |
| Port Style | Barbless |
| Features | Temperature Compensated |
| Termination Style | Gull Wing |
| Maximum Pressure | 58.02PSI (400kPa) |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing, Top Port |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MPXA4100A6T1 | MPXA4100A6U | MPXA4115A6T1 | MPXA4115A6U |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SENSOR 15.23PSIA 49V | SENSOR 15.23PSIA 49V | SENSOR 16.68PSIA 4.8V 8SOP | SENSOR 16.68PSIA 4.8V |
| Series | MPXA4100A | MPXA4100A | MPXA4115A | MPXA4115A |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR) | Tube |
