MSD1278H-684KED
Manufacturer
CoilcraftDescription
FIXED INDUCTOR 680UH SMD
Datasheet
DatasheetPackage
Nonstandard
In Stock
83,694 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MSD1278H-684KED
MSD1278H-684KED
lmages are for reference only.Payment Methods
Delivery Services
Shielded 2 Coil Inductor Array 2.72 mH Inductance - Connected in Series 680 µH Inductance - Connected in Parallel 890mOhm Max DC Resistance (DCR) - Parallel Nonstandard
Quick Inquiry
MSD1278H-684KED
Specifications
| Category | Inductors, Coils, Chokes - Arrays-Signal Transformers - |
| Manufacturer | Coilcraft |
| Series | MSD1278H |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Number of Coils | 2 |
| Inductance - Connected In Parallel | 680 µH |
| Inductance - Connected In Series | 2.72 mH |
| Tolerance | ±10% |
| Current Rating - Parallel | - |
| Current Rating - Series | - |
| Current Saturation - Parallel | - |
| Current Saturation - Series | - |
| DC Resistance (DCR) - Parallel | 890mOhm Max |
| DC Resistance (DCR) - Series | 3.56Ohm Max |
| Shielding | Shielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.484" L x 0.484" W (12.30mm x 12.30mm) |
| Height | 0.317" (8.05mm) |
| Base Product Number | - |
