MSJPF08N90A-BP
lmages are for reference only.MSJPF08N90A-BP
N-CHANNEL MOSFET,TO-220F
DatasheetTO-220-3 Full Pack
14,771 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 900 V 8A (Tc) 113W (Tc) Through Hole TO-220F
MSJPF08N90A-BP
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 900 V |
| Current - Continuous Drain (Id) @ 25°C | 8A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 1.3Ohm @ 2.5A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 474 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 113W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220F |
| Package / Case | TO-220-3 Full Pack |
| Base Product Number | MSJPF08 |
| Gate Charge (Qg) (Max) @ Vgs | 13.6 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MSJP06N80A-BP | MSJP07N80A-BP | MSJP08N90A-BP | MSJP09N65A-BP |
| Manufacturer | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | Interface | MOSFET | N-CHANNEL MOSFET,TO-220AB(H) | N-CHANNEL MOSFET, TO-220AB(H) |
| Series | - | - | - | - |
| Packaging | Bulk | Tape & Reel (TR) | Tube | Tube |
