NACZ102M6.3V8X10.5TR15F
lmages are for reference only.NACZ102M6.3V8X10.5TR15F
CAP ALUM 6.3V POLAR
DatasheetRadial, Can - SMD
77,632 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1000 µF 6.3 V Aluminum Electrolytic Capacitors Radial, Can - SMD 170mOhm @ 100kHz 2000 Hrs @ 105°C
NACZ102M6.3V8X10.5TR15F
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | NIC Components Corp |
| Series | NACZ |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | 170mOhm @ 100kHz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | - |
| Ripple Current @ Low Frequency | - |
| Ripple Current @ High Frequency | 450 mA @ 100 kHz |
| Lead Spacing | - |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | 0.327" L x 0.327" W (8.30mm x 8.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Base Product Number | - |
| Impedance | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | NACZ102M6.3V8X10.5TR13F | NACE100M16V4X5.5TR13F | NACE100M35V5X5.5TR13F | NACE100M50V6.3X5.5TR13F |
| Manufacturer | NIC Components Corp | NIC Components Corp | NIC Components Corp | NIC Components Corp |
| RoHS Status | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | CAP ALUM 1MF 20% 6.3V SMD | CAP ALUM 10UF 20% 16V SMD | CAP ALUM 35V POLAR | CAP ALUM 10UF 20% 50V SMD |
| Series | NIC Components Corp | NIC Components Corp | NIC Components Corp | NIC Components Corp |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
