RF Switch IC General Purpose SPDT 3 GHz 50Ohm 8-VSP
NJG1506R-TE2
| Category | RF and Wireless - RF Switches - |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| RF Type | General Purpose |
| Topology | Reflective |
| Circuit | SPDT |
| Frequency Range | 50MHz ~ 3GHz |
| Isolation | 27dB |
| Insertion Loss | 0.5dB |
| Test Frequency | 2GHz |
| P1dB | 22dBm |
| IIP3 | - |
| Features | - |
| Impedance | 50Ohm |
| Voltage - Supply | 2.5V ~ 5.5V |
| Operating Temperature | -30°C ~ 85°C |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 8-VSP |
| Base Product Number | - |
| Mounting Type | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | NJG1506R-TE2 | NJG1505R-TE1 | NJG1505R-TE1 | NJG1507R-TE1 |
| Manufacturer | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| RoHS Status | RoHS non-compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | IC RF SWITCH SPDT 3GHZ 8VSP | IC RF SWITCH SPDT 3GHZ 8VSP | IC RF SWITCH SPDT 3GHZ 8VSP | IC RF SWITCH SPDT 3GHZ 8VSP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
