N-Channel 25 V 7.8A (Ta), 45A (Tc) 1.5W (Ta), 50W (Tc) Surface Mount DPAK
NTD50N03R
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 25 V |
| Current - Continuous Drain (Id) @ 25°C | 7.8A (Ta), 45A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 11.5V |
| Rds On (Max) @ Id, Vgs | 12mOhm @ 30A, 11.5V |
| Vgs(th) (Max) @ Id | 2V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 750 pF @ 12 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.5W (Ta), 50W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | DPAK |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Base Product Number | NTD50 |
| Gate Charge (Qg) (Max) @ Vgs | 15 nC @ 11.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | NTD50N03R-001 | NTD50N03R-1G | NTD50N03R-35G | NTD50N03RG |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | RoHS non-compliant | |||
| Description | MOSFET N-CH 25V 7.8A/45A IPAK | MOSFET N-CH 25V 7.8A/45A IPAK | MOSFET N-CH 25V 7.8A/45A IPAK | MOSFET N-CH 25V 7.8A/45A DPAK |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
