PESD2V0Y1BSFYL
lmages are for reference only.PESD2V0Y1BSFYL
TVS DIODE 2VWM 3VC DSN0603-2
Datasheet0201 (0603 Metric)
55,588 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
3V (Typ) Clamp 6A (8/20µs) Ipp Tvs Diode Surface Mount DSN0603-2
PESD2V0Y1BSFYL
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Nexperia USA Inc. |
| Series | TrEOS |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 2V (Max) |
| Voltage - Breakdown (Min) | 3.3V (Typ) |
| Voltage - Clamping (Max) @ Ipp | 3V (Typ) |
| Current - Peak Pulse (10/1000µs) | 6A (8/20µs) |
| Power - Peak Pulse | - |
| Power Line Protection | No |
| Applications | USB |
| Capacitance @ Frequency | 0.69pF @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 0201 (0603 Metric) |
| Supplier Device Package | DSN0603-2 |
| Base Product Number | PESD2V0 |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | PESD2V0Y1BHMYL | PESD0402-060 | PESD0402-140 | PESD0402-240 |
| Manufacturer | Nexperia USA Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | PESD2V0Y1BHM/SOD962H/DSN0603-2 | TVS DIODE 6VWM 0402 | TVS DIODE 14VWM 40VC 0402 | TVS DIODE 24VWM 40VC 0402 |
| Series | Nexperia USA Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
