MOSFET 2N-CH 40V 10A 8DFN
Datasheet8-PowerTDFN
25,170 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 40V 10A (Ta), 45A (Tc) 1.7W (Ta), 32W (Tc) Surface Mount DFN5060B-8
PJQ5844_R2_00001
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Panjit International Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 40V |
| Current - Continuous Drain (Id) @ 25°C | 10A (Ta), 45A (Tc) |
| Rds On (Max) @ Id, Vgs | 8mOhm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 17nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 1759pF @ 25V |
| Power - Max | 1.7W (Ta), 32W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerTDFN |
| Supplier Device Package | DFN5060B-8 |
| Base Product Number | PJQ5844 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
|
| Part Number | PJQ5844-AU_R2_000A1 | PJQ5846-AU_R2_000A1 | PJQ5846_R2_00001 | PJQ5848-AU_R2_000A1 |
| Manufacturer | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET 2N-CH 40V 10A 8DFN | MOSFET 2N-CH 40V 9.5A 8DFN | MOSFET 2N-CH 40V 9.5A 8DFN | MOSFET 2N-CH 40V 8.6A 8DFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
